where the power supply exhibits the lowest impedance; and the audio signal grounding occur at a spur leading from the power supply ground.

Bipolar power supply as drawn

Bipolar power supply as implemented on a printed circuit board

Bipolar power supply as should be implemented

    If these two steps have been followed, then making a shunt regulator for a bipolar power supply becomes both easier and more efficient.

    But before getting into the design of a shunt regulator, lets first look an alternative, passive approach. Obviously, an inductor (choke) can be added to each power supply rail. Not so obvious is that a special type of inductor, the dual winding inductor, can be used. This type of inductor comes in two styles: air-gapped and not

Single winding and dual winding inductors
